Technical Index:
Laser Type: CO2 Sealed-off laser glass tube
Laser Power: 50/60W
Cutting Size: 400 * 600mm.
Engraving Speed: 0-500mm/sec.
Cutting speed: 0-300mm/sec.
Laser Energy Control: 1-100% software setting
Min. cutting character: Chinese character: 2x2mm, English letter: 1x1mm
Max. Scanning Accuracy: 2500DPI
Positioning Accuracy: <+/-0.01mm
Total power: <1000W
Supporting Figure Format: DST, PLT, BMP, DXF, AI
Supporting Software: CORELDRAW, PHOTOSHOP, AUTOCAD, CAD, TAJIMA.
Color Separation: Yes
Machine Size: 1060*770*880mm
Packing Size: 1160*870*1060mm
Power Voltage: 220V, 50HZ/110V/60HZ
Net Weight: 130 kgs.
Optional Parts: Up-down worktable, Autofocus
Applicable industry:
Advertis singboard, arts & crafts, crystal, embossment technology, printing plate making, clothing & leather, embroidery engraving and cutting.
Applicable Materials:
Non-metal materials: such as rubber, plastic, crystal, Plexiglas, acrylics, bamboo and wooden, marble, China, paper, garment, jade article, glass etc.
Liaocheng Hongqiang Electronic Equipment Co., Ltd, as a professional manufacturer and exporter of CNC laser engraving cutting marking welding cleaning machine, is dedicated to provide the best laser machines and services to global customers on high standard on high precise materials processing industry. SEE MORE
