Technical Index:
Laser power: 50/60W (OPTIONAL)
Laser Type: CO2 Sealed-off Glass-tube laser
Power supply: AC220V +/- 10%, 50HZ/AC110V+/- 10%, 60Hz
Max. Engraving size: 500 * 300mm
Engraving speed: 0-5000mm/sec.
Cutting speed: 0-300mm/sec.
Platform: Up-down platform/Fixed platform
Locating Precision: <0.01mm
Total power: <1000W
Number of Hanged Line: 60 lines
Min. shaping character: Character: 2x2mm, Letter: 1x1mm
Operating Temperature: 5℃-35℃
Resolution: <4500dpi
Control Configuration: DSP
System Environment: WINDOWS2000/WINDOWS XP/Vista/Win7
Type of Cooling: water-cooling and protection system
Graphic Format Supported: ALL FORMTS RECOGNIZABLE BY CORELDRAW, AUTOCAD
Cutting Thickness: 0-6mm (Depends on different materials)
Cut by color separation: reaches 256 colors to cut
Water-break protection: Yes
Gradient Engraving: Yes, gradient adjustable
Machine Weight: 85 kgs (187 lbs)
Machine Dimension: 1220*650*960mm
Packing Dimension: 1320*750*1060mm (41.2*25.9*35.6")
Gross Weight: 100 kgs (220 lbs)
Optional Parts: Up-down worktable, Rotary attachment, Autofocus, Water Chiller.
Applicable Industry:
Cutting, engraving, through-carved, hole drilling on wood and bamboo, acrylic, craft and gift, crystal,
marble and granite, ceramic, glass and other non-metal materials. It is widely used in electronic, craft and gift, advertising industries.
