Technical Index:
Laser Style: CO2 Sealed-Off laser glass tube, water-cooled
Laser power: 100/130/150W
Engraving size: 1200*900mm
Engraving speed: 0-60000mm/min
Positional Accuracy: <+/-0.01mm
Power supply: AC220V/50Hz, AC110V/60Hz
Total Power: <500W
Operating temperature: 0-45 degree centigrate
Operating Moisture: 5-95%
Maximum engraving depth: 3.5mm
Minimum cutting character: English letter: 1.0 * 1.0mm
Available Figure Format: BMP, PLT, DST, DXF, AI
Supporting Software: CorelDraw, PhotoShop, AutoCAD,TAJIMA
Driving System: 2 phases stepper motor
Machine Dimension: 1680 * 1330 * 920mm
Packing Dimension: 1790 * 1440 * 1120mm
Gross Weight: 280kg
Applicable Industry:
Cutting, engraving, through-carved, hole drilling on wood and bamboo, acrylic, craft and gift, garment and leather,
marble and granite, ceramic, glass and other non-metal materials.
