Techinical Index:
Laser power: 3W/5W Air Cooled UV laser
Working area: 110*110mm. 150*150mm/200*200mm/300*300mm (Optional)
Laser Wave length: 355nm
Response time: 0.5ms
Frequency of pulse: 20-100KHz
Max marking depth: ≤0.4mm
Marking speed: ≤10000mm/s
Marking lines: 1-10 lines(in the marking area)
Minimum line width: 0.005mm
Minimum character: 0.15mm
Repeatability accuracy: ±0.001mm
Resolution ratio: 0.1mm
Marking content: Text,pattern,date,bar code,etc
Operation system: Microsoft Windows XP,Windows 2000, Window 7
Control software: EZCAD control software
Graphic format support: bmp, jpg, gif, tga, Ai, bmp, dst, dxf, plt, png, tif, ai, dxf, dst, plt
Total power: ≤300KW
Operation temperature: 5℃-40℃
Relative moisture: ≤ 90%, no fog
Supply Voltage: 220V/50Hz/10A
Life: 50000 hours
Cooling: Air cooling
Application:
Suitable for: anodized sculpture, hand tools deep carved, aluminum a deep carved, stainless steel surface carved black, IC table sculpture, etc.
