Technical Index:
Laser Type: CO2 Sealed-off laser glass tube, water-cooled
Laser Power: 100/130W
Cutting Area: 900 * 600mm.
Engraving Speed: 0-500mm/sec.
Cutting Speed: 0-300mm/sec.
Min.cutting character: Chinese character: 2x2mm, English letter: 1x1mm
Positioning Accuracy: <+/-0.01mm
Total power: <1200W
Supporting Figure Format: DST, PLT, BMP, DXF, AI, LAS
Supporting Software: CORELDRAW, PHOTOSHOP, AUTOCAD, CAD, TAJIMA.
Color Separation: Yes
Driving System: 2 phases stepper motor
Operating Platform: Up and Down, Lifting Height: 500mm
Working Environment: Temperature: 0-45 degree centigrate, Moisture: 5%-95%.
Machine Size: 1450*1090*1140mm
Packing Size: 1550*1190*1240mm
Power Voltage: 220V/ 50HZ; 110V/60HZ
Gross Weight: 230 kgs.
Driving: Servo motor and driver
Transmission: Rack
Optional Parts: Up-down worktable, Autofocus
Applicable industry:
Advertis singboard, arts & crafts, crystal, embossment technology, printing plate making, clothing & leather, embroidery engraving and cutting.
Applicable Materials:
Non-metal materials: such as rubber, plastic, crystal, Plexiglas, acrylics, bamboo and wooden, marble, China, paper, garment, jade article, glass etc.
Video:
Qingdao Mektex Electronic Technology Co., Ltd, as a professional manufacturer and exporter of CNC laser engraving cutting marking welding cleaning machine, is dedicated to provide the best laser machines and services to global customers on high standard on high precise materials processing industry. SEE MORE
