Technical Index:

Laser Type: CO2 Sealed-off laser glass tube

Controller: Ruida 6442G

Laser Power: 50/60W

Cutting Size: 400 * 400mm.

Engraving Speed: 0-500mm/sec.

Cutting speed: 0-300mm/sec.

Laser Energy Control: 1-100% software setting

Min. cutting character: Chinese character: 2x2mm, English letter: 1x1mm

Max. Scanning Accuracy: 2500DPI

Positioning Accuracy: <+/-0.01mm

Toal power: <1000W

Supporting Figure Format: DST, PLT, BMP, DXF, AI

Supporting Software: CORELDRAW, PHOTOSHOP, AUTOCAD, CAD, TAJIMA.

Color Separation: Yes

Machine Size: 880*720*450mm

Packing Size: 980*820*550mm

Power Voltage: 220V, 50HZ/110V/60HZ

Gross Weight: 60 kgs.

Optional Parts: Up-down worktable, Autofocus.

Applicable industry:

Advertis singboard, arts & crafts, crystal, embossment technology, printing plate making, clothing & leather, embroidery engraving and cutting.

Applicable Materials:

Non-metal materials: such as rubber, plastic, crystal, Plexiglas, acrylics, bamboo and wooden, marble, China, paper, garment, jade article, glass etc.
