Technical Index:
Laser power: 150/180/200/260/300/400W (Optional)
Laser Type: CO2 Sealed-off laser glass tube, water-cooled
Engraving size: 1500*3000mm
Engraving speed: 0-400mm/sec.
Cutting speed: 0-200mm/sec.
Laser Energy Control: Adjustable
Max. Scanning Accuracy: 25-2500DPI
Figure Supported: DST, HPGL (PLT), BMP, DXF, AI, DST, JPEG
Software Supported: TAJIMA, CORELDRAW, PHOTOSHOP, AUTOCAD, CAM
Color Separation: Yes, 256 layers
Machine Dimension: 3750*2130*1280mm
Packing size: 3850*2230*1380mm
Gross weight: 800kgs
Total Power: <1200W
Communication Connection: USB (off-line) or computer control
Working Voltage: 220V+/-10% 50Hz, or 110V 60 Hz
Moving System: DSP Professional Controlling System
Repeating Location: <+0.01
Applicable Industry:
Cutting, engraving, through-carved, hole drilling on textile, garment, leather, cotton & linen fabric, glass, wood,
bamboo, arcylic board etc non-metal materials.
Video:
https://youtu.be/vksr5iSIbdM (Ruida Operation Manual)
https://youtu.be/UOaU3_gzuAQ (Engraving On Ceramic)
https://youtu.be/MDFKy2BSgZg (Engraving on Marble)
Liaocheng Hongqiang Electronic Equipment Co., Ltd, as a professional manufacturer and exporter of CNC laser engraving cutting marking welding cleaning machine, is dedicated to provide the best laser machines and services to global customers on high standard on high precise materials processing industry. SEE MORE
